| ltem | Description | |||||
|---|---|---|---|---|---|---|
| Type | 2-3/8in(60.3mm) | 2-7/8in (73.0mm) | ||||
| Part No. | RMUBSN238795A0 | RMUBSN238795B0 | RMUBSN238795C0 | RMUBSN278930A0 | RMUBSN278930B0 | |
| Size of Glass | 1/2” | 3/4” | 3/8” | 1/2” | 3/4” | |
| Max.Diferential | 24MPa | 48MPa | 16MPa | 17.2MPa | 27.6MPa | |
| O.D MAX | 79.5mm | 93mm | ||||
| I.D. | 48mm | 60mm | ||||
| Connection | UPPER Thread | 2-3/8 EU BOX | 2-7/8 EU BOX | |||
| Bottom Thread | 2-3/8 EU PIN | 2-7/8 EU PIN | ||||
| Flow Area of Ports | 5338mm² | |||||
| Make-up Length | 300mm | |||||
